Šifra proizvoda: HDCH8S25330
Naziv: Modularni kontaktor 25A 3P 3NO HDCH8S Himel
Range of product:HDCH8s
Product or component type:Modular contactor
Contactor application:Lighting Motor control Heating
Poles description:3P
Pole contact composition:3 NO
[Ie] rated operational current:25 A AC-7A
Utilisation category:AC-7A AC-7B
[Ue] rated operational voltage:250/400 V
Control circuit type:AC at 50/60 Hz
[Uc] control circuit voltage:230 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage:4 kV
[Ith] conventional free air thermal current:25 A
Irms rated making capacity:37.5 A
Rated breaking capacity:37.5 A
[Ui] rated insulation voltage:500 V
Electrical durability:100000 cycles
Control type:Remote control
Mounting mode:Clip-on
Mounting support:DIN rail
Maximum operating rate:30 cyc/h
Mechanical durability:1000000 cycles
Standards:IEC 61095
Ambient air temperature for operation:-5…60 °C
Unit Type of Package 1:PCE
Na lageru: 38 kom
Jedinica mere: kom
->
